$1,999.00
The Katool KT-H100 is a 10,000 lb. baseplate two-post vehicle lift built for professional bays, performance garages, and serious home shop service work.
The Katool KT-H100 is a 10,000 lb. baseplate two-post vehicle lift built for professional bays, performance garages, and serious home shop service work.
| Model | KT-H100 |
|---|---|
| Lift Type | Baseplate two-post vehicle lift |
| Lifting Capacity | 10,000 lb. |
| Max. Lifting Height | 70.75″ |
| Minimum Pad Height | 4.25″ |
| Overall Height | 110.25″ |
| Overall Width | 142.25″ |
| Inside Column Width | 110.25″ |
| Drive-Through Clearance | 94.5″ |
| Arm Reach | 30.75″–50.5″ front/rear, 2-stage |
| Motor / Power | 220 VAC / 60 Hz / 1 Ph / 2.2 kW; optional 110V configuration |
| Net Weight | Approx. 1,256 lb. |
| Weight | 1256 lbs |
|---|---|
| Lift Type | Two-Post |
| Lifting Capacity (lb) | 10000.0 |
| Lifting Capacity Range | 10000-11999 lb |
| Max Rise (in) | 70.75 |
| Max Lifting Height (in) | 70.75 |
| Overall Width (in) | 142.25 |
| Overall Height (in) | 110.25 |
| Width Between Posts (in) | 110.25 |
| Drive-Thru Width (in) | 94.5 |
| Configuration | Baseplate |
| Lift Style | Symmetric |
| Power Requirements | 220V / 1 Phase / 2.2kW |
