$1,899.00
The Katool KT-H105 is a 10,000 lb. baseplate two-post vehicle lift built for cars, SUVs, and light-duty trucks in commercial repair shops and serious home garages.
The Katool KT-H105 is a 10,000 lb. baseplate two-post vehicle lift built for cars, SUVs, and light-duty trucks in commercial repair shops and serious home garages.
| Model | KT-H105 |
|---|---|
| Lift Type | Baseplate two-post vehicle lift |
| Lifting Capacity | 10,000 lb. |
| Max. Lifting Height | 70.8″ |
| Minimum Height | 3.9″ |
| Overall Height | 110.9″ |
| Overall Width | 140.4″ |
| Outside Column Width | 124.8″ |
| Inside Column Width | 110.2″ |
| Drive-Thru Clearance | 98.4″ |
| Front Arm Reach | 29.5″–46″, 2-stage |
| Rear Arm Reach | 35.4″–58.3″, 2-stage |
| Motor | 220 VAC / 60 Hz / 1 Ph / 2.2 kW |
| Concrete Requirement | 5.9″ minimum / 3,000 PSI |
| Net Weight | Approx. 1,257 lb. |
| Weight | 1257 lbs |
|---|---|
| Lift Type | Two-Post |
| Lifting Capacity (lb) | 10000.0 |
| Lifting Capacity Range | 10000-11999 lb |
| Max Rise (in) | 70.8 |
| Max Lifting Height (in) | 70.8 |
| Overall Width (in) | 140.4 |
| Overall Height (in) | 110.9 |
| Width Between Posts (in) | 110.2 |
| Drive-Thru Width (in) | 98.4 |
| Configuration | Baseplate |
| Lift Style | Symmetric |
| Concrete Requirement | 5.9 in / 3000 PSI |
| Power Requirements | 220V / 1 Phase / 2.2kW |
